A sports watch’s 9-axis accelerometer: is it actually better than a 3- or 6-axis?

Most of us know an accelerometer helps our watch hold position when GPS struggles, and most of us want accuracy, so which type should we be looking for: 3-axis, 6-axis, or 9-axis? Nine intuitively sounds best. The answer depends on where you train.

The sensor doing this work is a combined motion sensor called an IMU, which measures acceleration and rotation, with the axis count indicating how many measurement channels it contains rather than simply dimensions in space, which are limited to 3!

---

3-axis: the accelerometer

An accelerometer measures force in three directions: forward-back, left-right, and up-down. Think of it as the sensor that feels the push, not the turn: enough for step counting, cadence, jump detection, and basic rep counting, but it has no knowledge of how the body is oriented or rotating.

For straight-line running, it can be an adequate corrector of GPS position; for a sled push, wall ball, or rowing stroke, speed and distance figures are pattern-matched guesses rather than measurements.

---

6-axis: acceleration plus rotation

A rotation sensor (gyroscope) measures how fast the device is turning around each axis, an extra measurement of each of the 3 dimensions, which produces a 6-axis IMU: this is the combination that underpins serious sports tracking. Stryd is a good example.

• Stryd runs a 6-axis core with an altimeter and wind meter; indoors, its foot-mounted motion models track each stride directly rather than inferring movement from wrist swing.
• Stryd moved to the foot to measure each stride directly; the Garmin RD Pod stays at the waistband, where ground contact time broadly agrees, but vertical oscillation diverges because each device is measuring a different body segment.

The problem with a 6-axis sensor is drift. The rotation sensor accumulates small errors over tens of minutes during repeated direction changes.

---

9-axis: adding a compass

A 9-axis IMU adds a digital compass (magnetometer), providing an absolute heading reference that corrects 6-axis rotational drift. The Garmin Fenix 8 and Apple Watch Ultra 3 both use 9-axis hardware for that reason.

Indoors, steel structures and electrical equipment distort the local magnetic field enough to make the compass unreliable, and both the Fenix 8 and Apple Watch Ultra 3 revert to accelerometer-based calculation for indoor profiles. In effect, two of the most advanced sports watches available treat the ninth axis as an outdoor-only feature.

The exception is events with repeated laps and direction changes, where a compass, even partially corrupted by magnetic distortion, corrects turn errors that a rotation sensor alone accumulates lap by lap.

---

Axis count versus real-world accuracy

Axis count describes theoretical capability, as many other factors come into play, such as sensor quality, calibration, and fusion algorithms. In fact, there are quite a few sources of error to contend with:

• Sample rate: lower rates underestimate short-duration peaks such as jump impacts or explosive drive initiation
• Sensor noise floor: budget sensors bury low-force signals; slow or controlled movements are most affected
• Rotation sensor drift: compounds with session duration; the primary error source during long indoor efforts
• Magnetic interference: steel structures and powered equipment distort compass output; worst in gym and competition hall environments
• Sensor placement: soft tissue filters and delays the signal; rigid mounting near the body’s centre of mass captures whole-body movement that a wrist strap cannot
• Temperature: rotation sensors drift with temperature; devices without compensation behave differently from cold start to mid-session
• Calibration: a poorly calibrated device produces consistently wrong data, worsened if manual calibration is required

---

Beyond 9-axis

Barometric pressure is already integrated alongside the IMU in Stryd and the Fenix 8, adding a vertical reference when IMU-derived altitude and GPS diverge.

A more significant development would be one or more additional sensors working alongside the watch. A body-mounted sensor captures whole-body movement the watch cannot see; where station loads are standardised, load can be inferred from mass and acceleration alone. A sensor on each limb captures left-right differences in speed, range of motion, and acceleration, identifying not just the exercise but how it is being executed.

Stryd’s own documentation notes that wrist-based and waist-worn sensors share two fundamental limitations: reliance on GPS data and reliance on sensors at the wrist. Foot placement, it argues, removes both.

---
